1.7. RESULTS MENU
This menu allows the display of the results measured by the different measurement
units.
In this menu the 64 last results of all the heads are conserved.
In the "RESULTS/GENERAL" menu, all the measurements of all the units will be
displayed.
In the "RESULTS/HEADXX" menu, all the measurements of the corresponding
measurement unit (head) will be displayed.
In the display of the results you will find:
9 the number of the unit,
9 le number of the program,
9 the test result,
9 the measurements.
In the display of the test results, there is: POK, good part; PNOK, test error; AL, alarm.
On the current display, the last 9 results
are displayed.
RESULTS
H01 01 (OK)° 053 Pa 1.99 bar
H02 01 (OK)° 002 Pa 792.9 mbar
H01 01 (OK)° 057 Pa 1.99 bar
H02 01 (OK)° 003 Pa 794.8 mbar
H01 01 (OK)° 056 Pa 1.99 bar
H02 01 (OK)° 001 Pa 796.0 mbar
H01 01 (OK)° 051 Pa 1.99 bar
H02 01 (OK)° 000 Pa 798.7 mbar
H01 01 (OK)° 048 Pa 1.99 bar
15:33:32 08/07/2002
If the "ENTER" key is pressed, a
window opens, it is then possible to
manage the results.
PRINT: to send the results and the time
stamping to the printer which is
connected to the central.
RESET: to definitively erase the results
displayed on the screen.
RESULTS
H01 01 (OK)° 053 Pa 1.99 bar
H02 01 (OK)° 002 Pa 792.9 mbar
H01 01 (OK)° 057 Pa 1.99 bar
H02 01 (OK)° 003 Pa 794.8 mbar
H01 01 (OK)° 056 Pa 1.99 bar
H02 01 (OK)° 001 Pa 796.0 mbar
H01 01 (OK)° 051 Pa 1.99 bar
H02 01 (OK)° 000 Pa 798.7 mbar
H01 01 (OK)° 048 Pa 1.99 bar
15:33:32 08/07/2002
PRINT
RESET
To Next Page
