Manual, F/T Sensor, Data Acquisition (DAQ) Systems
Document #9620-05-DAQ.indd-20
Pinnacle Park • 1031 Goodworth Drive • Apex, NC 27539 • Tel: 919.772.0115 • Fax: 919.772.8259 • www.ati-ia.com • Email: info@ati-ia.com
27
Table 4.1—Unterminated Cable (9105-C-PS-U-x) for a NI 32 and 64 Pin Screw Terminal DAQ Device
NI 32 or 64
Pin # and Screw
Terminal Labels
Description Wire Colors
NI 64 Pin # and
Screw Terminal
Labels
Description Wire Colors
1 PFI 0/P0.0 (In) No ATI Connection N/A 33 PFI 8/P0.4 (In) No ATI Connection N/A
2 PFI 1/P0.1 (In) No ATI Connection N/A 34 PFI 9/P0.5 (In) No ATI Connection N/A
3 PFI 2/P0.2 (In) No ATI Connection N/A 35 PFI 10/P0.6 (In) No ATI Connection N/A
4 PFI 3/P0.3 (In) No ATI Connection N/A 36 PFI 11/P0.7 (In) No ATI Connection N/A
5 D GND No ATI Connection
1
N/A
1
37 D GND No ATI Connection
1
N/A
1
6 PFI 4/P1.0 (Out) No ATI Connection N/A 38 PFI 12/P1.4 (Out) No ATI Connection N/A
7 PFI 5/P1.1 (Out) No ATI Connection N/A 39 PFI 13/P1.5 (Out) No ATI Connection N/A
8 PFI 6/P1.2 (Out) No ATI Connection N/A 40 PFI 14/P1.6 (Out) No ATI Connection N/A
9 PFI 7/P1.3 (Out) No ATI Connection N/A 41 PFI 15/P1.7 (Out) No ATI Connection N/A
10 +5V No ATI Connection
1
N/A
1
42 +5V No ATI Connection
1
N/A
1
11 D GND Shielding Twisted shielding 43 D GND Shielding
2
Twisted shielding
2
12 NC or AO 0 No ATI Connection N/A 44 NC No ATI Connection N/A
13 NC or AO 1 No ATI Connection N/A 45 NC No ATI Connection N/A
14 Reser or AO GND No ATI Connection N/A 46 AI GND No ATI Connection
N/A
15 AI 0 SG0 output Brown 47 AI 16 SG0 output
2
Brown
2
16 AI 8 SG0 reference Brown/White 48 AI 24 SG0 reference
2
Brown/White
2
17 AI 1 SG1 output Yellow 49 AI 17 SG1 output
2
Yellow
2
18 AI 9 SG1 reference Yellow/White 50 AI 25 SG1 reference
2
Yellow/White
2
19 AI 2 SG2 output Green 51 AI 18 SG2 output
2
Green
2
20 AI 10 SG2 reference Green/White 52 AI 26 SG2 reference
2
Green/White
2
21 AI 3 SG3 output Blue 53 AI 19 SG3 output
2
Blue
2
22 AI 11 SG3 reference Blue/White 54 AI 27 SG3 reference
2
Blue/White
2
23 AI SENSE No ATI Connection N/A 55 AI GND No ATI Connection N/A
24 AI 4 SG4 output Violet 56 AI 20 SG4 output
2
Violet
2
25 AI 12 SG4 reference Violet/White 57 AI 28 SG4 reference
2
Violet/White
2
26 AI 5 SG5 output Grey 58 AI 21 SG5 output
2
Grey
2
27 AI 13 SG5 reference Grey/White 59 AI 29 SG5 reference
2
Grey/White
2
28 AI GND AGnd power input Black 60 AI GND AI GND
2
Black
2
29 AI 6 No ATI Connection N/A 61 AI 22 No ATI Connection N/A
30 AI 14 No ATI Connection N/A 62 AI 30 No ATI Connection N/A
31 AI 7 No ATI Connection N/A 63 AI 23 No ATI Connection N/A
32 AI 15 No ATI Connection N/A 64 AI 31 No ATI Connection N/A
Notes: (Note # shown in table as superscript)
1. Do not connect the (+5V) red wire and the power ground (DGND) red/white wire on systems that have PS or
IFPS boxes with a 12 V wall mounted power supply. The (+5V) red wire and the power ground (DGND) red/white
wire are only required for systems that do not have a separate wall mounted power supply. Connect to external
power source, not the +5V through the USB.
2. Indicates the wired connection for the 2nd transducer and PS or IFPS box for NI 64 Pin screw terminal
connections only.
