Warnings
Installation
Use
• Smart Grid signal:
The Smart Grid is an intelligent electrical network that can be used to optimise the distri-
bution and consumption of electricity in real time.
Without a Smart Grid signal, the system is authorised to operate using one of the following
2 settings:
• as required
• during programmed time slots only
With the Smart Grid signal, the system is authorised to start and will operate up to its
setpoint.
Conguration
set on the
control panel
Range used
Between
terminals
11 and 12
Range status
Heating
possible
Setpoint
O󰀨-peak
hours
Time slot activated
based on O󰀨-peak
hours time slots
ON O󰀨-peak hour yes Normal
OFF Peak hour no
PV Preprogrammed
time slots
ON Within the pro-
grammed time slot
yes Max.
Outside the pro-
grammed time slot
yes
OFF Within the pro-
grammed time slot
yes Normal
Outside the pro-
grammed time slot
no
Smart Grid Time slots pro-
grammed by the
user
ON Within the pro-
grammed time slot
yes Max.
Outside the pro-
grammed time slot
yes
OFF Within the pro-
grammed time slot
yes Normal
Outside the pro-
grammed time slot
no
6.1.2. Heating times
This setting denes the permissible time slots for starting the heat pump and the electric back-
up in accordance with the hot water requirements. It can be congured if there is no connec-
tion to the off-peak hours signal, or to the photovoltaic own consumption signal.
