Warnings
Installation
Use
Size of openings: their minimum size Smin in cm² depends on the R32 charge and the
surface area of the room in which the product is installed. See table below.
Surface area of the room in which
the product is installed in m²
Cabinet
0.36~0.42
1 2 3 4 5 6
Minimum surface
area (Smin) of the
lower ventilation
grille in cm²
Vertical
wall-
mounted
300
250
200 150 100 50 -
Vertical
oor-stand-
ing
550 550 500 450 450 400 -
5.4. Location
Installation in sealed cabinet prohibited.
5.4.1. Installation site of the water heater, 270 l version
Floor bearing capacity:
• Load capacity of at least 400 kg for the surface area bear-
ing the water heater
Height underneath the
ceiling:
• > 1.70 m
Recommended installa-
tion site:
• In heated rooms
656
670
605
605
631
without the pressure relief valve
without the pressure relief valve
recommended
