14. Ohmic values of the sensors according to the
temperature
Outside unit discharge sensor / condenser sensor
° C K ohm ° C K ohm ° C K ohm
0 169 40 26 80 6.3
5 130 45 22 85 5.4
10 101 50 18 90 4.6
15 79 55 15 95 4
20 63 60 12 100 3.4
25 50 65 10 105 3
30 40 70 8.7 110 2.6
35 32 75 7.4 115 2.3
120 2
Outside unit evaporator sensor
° C K ohm ° C K ohm ° C K ohm
-30 96 10 9.6 50 1.7
-25 69 15 7.6 55 1.4
-20 50 20 6 60 1.2
-15 37 25 4.8 65 1
-10 28 30 3.8 70 0.8
-5 21 35 3.1 75 0.7
0 16 40 2.5 80 0.6
5 12 45 2.1
Outside unit air sensor / middle tank sensor / tank top sensor
° C K ohm ° C K ohm ° C K ohm
-10 62 20 13 50 3.5
-5 47 25 10 55 2.8
0 35 30 8 60 2.4
5 27 35 6.4 65 2
10 21 40 5.2 70 1.6
15 16 45 4.2 75 1.4
80 1.2
