Atlas Copco DWS VSD+ User Manual

Fault code Fault description
171 Control Circuit Error (CPF42)
172 Control Circuit Error (CPF43)
173 Control Circuit Error (CPF44)
174 Control Circuit Error (CPF45)
257 Option Compatibility Error (oFA00)
258 Option Not Properly Connected (oFA01)
259 Same Type of Option Card Already Connected (oFA02)
262 A/D Conversion Error (oFA05)
263 Option Response Error (oFA06)
273 Option RAM Fault (oFA10)
274 Option Operation Mode Fault (SLMOD) (oFA11)
275 Drive Receive CRC Error (oFA12)
276 Drive Receive Frame Error (oFA13)
277 Drive Receive Abort Error (oFA14)
278 Option Receive CRC Error (oFA15)
279 Option Receive Frame Error (oFA16)
280 Option Receive Abort Error (oFA17)
305 Comm. ID Error (oFA30)
306 Model Code Error (oFA31)
307 Sumcheck Error (oFA32)
308 Comm. Option Timeout Waiting for Response (oFA33)
309 MEMOBUS Timeout (oFA34)
310 Drive Timeout Waiting for Response (oFA35)
311 CI Check Error (oFA36)
312 Drive Timeout Waiting for Response (oFA37)
313 Control Command Selection Error (oFA38)
314 Drive Timeout Waiting for Response (oFA39)
315 Control Response Selection 1 Error (oFA40)
316 Drive Timeout Waiting for Response (oFA41)
317 Control Response Selection 2 Error (oFA42)
318 Control Response Selection Error (oFA43)
513 Option Compatibility Error (oFB00)
514 Option Connection Error (oFb01)
515 Same Type of Option Card Already Connected (oFb02)
518 A/D Conversion Error (oFb05)
519 Option Response Error (oFb06)
529 Option RAM Fault (oFb10)
530 Option Operation Mode Fault (SLMOD) (oFb11)
531 Drive Receive CRC Error (oFb12)
07/2021 - ©Atlas CopcoPage 1211950840208_A
