WARNING:
Ensure that the dry pumping system and the electrical supply cable are suitably
protected against earth (ground) faults and that the earth (ground) conductor of
the electrical supply cable is longer than the phase conductors in the connector.
WARNING:
Second protective earth (ground) conductor (with a cross-sectional area at least
equal to the phase conductor size up to 16 mm
2
) must be fitted to the protective
earth (ground) stud. Refer to Side view on page 12.
WARNING:
The power wiring to the dry pumping system must be properly protected.
CAUTION:
To ensure compliance with European Electromagnetic Compatibility (EMC)
requirements for EMC emissions, note that it is not intended for use in domestic
buildings, or in the properties directly connected to an electrical supply network
which also supplies domestic buildings.
To use the dry pumping system with a power supply in a different voltage range
to that specified on the rating plate, contact us.
The dry pumping system is protected from motor overloads and short circuits by
solid‑state electronics. The power wiring between the dry pumping system and
the electrical installation must be protected. When selecting input fuses, refer to
Electrical data on page 22. Pump rating information can be found on the label on
the rear of the pump.
T
o connect the electrical supply to the dry pumping system through an ELCB (or
RCD depending on territory) it must be suitable for protection of equipment with a
d.c. component in the fault current, for short duration switch‑on surges and high
leakage current (for example, type B, according to EN50178).
The secondary protective earth (ground) is required in case of a failure of the
primary earth and because pump filters can cause high earth leakage currents.
Refer to Table: General electrical data.
6.9.1. Mains supply cable connection
WARNING:
The mains terminal is not approved for connection and disconnection under
load.
Use the following instructions to make the electrical supply cable:
07/2021 - ©Atlas CopcoPage 931950840208_A
Installation
