FlexiROC T35 R/T40 R 10 Options
127 No: 3171473547.1 en
D Drain outlet.
E Drain cock.
The system is filled with pure water via (A) the pressure tank cap.
The system pressure can be read on (C) the tank pressure gauge.
The system is drained from water through the cock (E).
The system can be completely closed using a cock located on the pressure tank or air
cross.
Functions and settings
n The water mist system switch has three positions:
l Up - Fully open valves (Valve G).
l Neutral - Only the preset valve circuit is open (valve H).
l Down - OFF.
