Atlas Copco FlexiROC T35 R

To Next Page

To Previous Page

FlexiROC T35 R/T40 R 10 Options

128 No: 3171473547.1 en

Water mist system.

F Fine adjustment of water mist

G Valve.

H Valve.

I Strainer

J Cock for adjusting the water mist system.
