FlexiROC T35 R/T40 R 5 Controls
52 No: 3171473547.1 en
1 Main menu
Main menu.
a Opens graphical presentation for diesel engine
b Opens graphical presentation for directional in-
strument
c Opens graphical presentation for hole length/ver-
tical depth
d Opens graphical presentation for statistics
e Opens graphic presentation for system status
f Opens graphical presentation for settings
g Clock
1 Engine information / Soot content
Switching between the display of engine information and soot content is performed with
function key F1.
Engine information
a Bar graph showing engine speed
