FlexiROC T35 R/T40 R 6 Operating
90 No: 3171473547.1 en
WARNING
Serious injury
Risk of dumping
u May cause severe personal injury and damage to property
u Keep the winch cable continuously taught
1.
Activate the remote control box (see chapter: Activating the remote control box).
2.
Make sure the remote-control box is in tramming mode. Knob S130, position (h).
3.
Check that the track oscillation lock is deactivated. Switch S445, position (a).
Switch Y224.
4.
Release the winch drum in order to pull out the wire. Switch Y224, position (b).
5.
Pull out the wire and fasten the eye to the anchor point.
6.
Lock the winch drum. Switch Y224, position (a).
