Changing to Alternate Connector Panels
The ATS-1 may be factory -configured with any of four connector
audio styles: XLR (Cannon), floating BNC, WE310 tip-ring-sleeve,
and 1/4" stereo tip-ring-sleeve. Each panel also has banana jacks in
parallel with its connectors. To later change to another connector
panel with a different connector configuration:
1. Remove the top and bottom covers as described earlier in this
section.
2. Clip the cable ties securing the cables from the connector panel to
the chassis.
3. Locate the two cables from the Analyzer Input connectors on the
panel to the Analyzer circuit board on the top side of the chassis.
Observe that each cable connects to the board connector
nearest its panel connector. Disconnect these cables from the
circuit board.
4. Locate the two cables from the Generator Output connectors on
the panel to the Generator circuit board on the bottom side of
the chassis. Observe that each cable connects to the board
connector nearest its panel connector. Disconnect these cables
from the circuit board.
5. Remove the four #6-32 nuts which secure the connector panel to
the chassis, and remove the old panel.
6. Mount the new connector panel using the four #6-32 nuts
removed in the previous step.
7. Connect the Generator Output channel A cable to the Generator
A connector on the bottom circuit board. The wire with white
insulation goes to the pin marked + on the circuit board.
8. Connect the Generator Output channel B cable to the Generator
B connector on the bottom circuit board. The wire with white
insulation goes to the pin marked + on the circuit board.
9. Connect the Analyzer Input channel A cable to the Analyzer A
connector on the top circuit board. The wire with white
insulation goes to the pin marked + on the circuit board.
10. Connect the Analyzer Input channel B cable to the analyzer B
connector on the top circuit board. The wire with white
insulation goes to the pin marked + on the circuit board.
C Internal Changes
Appendix C - Performing Internal Changes Changing to Alternate Connector Panels
C-2 ATS-1 Dual Domain User's Manual
