Options Label
The Options Label (see Figure 1-5) specifies any options that are
installed in your Portable One Dual Domain. It is located on the lower
center of the rear panel.
The options label is filled out by the manufacturing technician when
configuring the instrument for the customer. If the IMD or EGZ options
are installed, an X will be placed in the appropriate box.
If option filters are installed, the type of filter will be marked in the
appropriate Optional Filters box.
The date of original manufacture will be written in the appropriate box.
If there are any other unique characteristics of the unit, codes will be
placed in the ‘Special’ box. These may be special modifications or
requirements from certain upgrade combinations.
Date of manufacture FW/DSP Version
Audio Measurement System
DUAL DOMAIN
Aux 2:
Aux 1:
Optional Filters:
Installed Options:
Special
EGZ Euro. Impedances
ATS-IMD Intermod. Distortion
Figure 1-5. Options label
1 Description
Description Options Label
ATS-1 Dual Domain User's Manual 1-9
