Gen Load Function
Measurement Range
<1 Ω to 20 kΩ
Accuracy
±[5 % + 0.5 Ω] for readings <1 kΩ
Degrades rapidly above 1 kΩ or with reactive
loads
Frequency Range
20 Hz - 20 kHz
Test Voltage
200 mV default. Usable from 10 mV to
generator maximum
Wow & Flutter Function
Test Signal Compatibility
2.80 kHz-3.35 kHz
Measurement Range
<0.005% to 3% (single range)
Accuracy (4 Hz)
±(5% of reading + 0.002%)
Detection Modes IEC/DIN (quasi-peak per IEC-386),
NAB (average),
JIS (per JIS 5551)
Response Selections
Weighted 4 Hz bandpass per IEC/DIN/NAB
Unweighted
0.5 Hz-200 Hz
Residual W+F
Weighted
≤0.005%
Unweighted
≤0.01%
Minimum Input
25 mV
10
Settling Time
IEC/DIN or NAB Typically 3-6 seconds
JIS
Typically 15-20 seconds
DIGITAL SIGNAL GENERATOR
DIGITAL OUTPUT CHARACTERISTICS
Output Formats AES/EBU (per AES3-1992)
SPDIF-EIAJ
Optical (Toslink
)
Sample Rates 28.8 kHz-52.8 kHz AES/EBU
57.6 kHz-105.6 kHz with 96 kHz option
Note 10 For fully specified performance. Usable with inputs as low as 10 mV. Readings are
disabled for in[uts below approximately 7 - 8 mV.
D Specifications
Appendix D - Specifications
ATS-1 Dual Domain User's Manual D-7
