Coding Error Displayed for total signal (both channels
combined)
AUXILIARY SIGNALS
Generator Auxiliary Signals
Analog Sync Output
LSTTL compatible signal that is intended to be
used as a trigger for stable oscilloscope
displays.
Digital Sync Output: (600mVpp nominal squarewave)
Selectable from:
Transmit Frame Sync Squarewave at the programmed internal sample
rate
Receive Frame Sync Squarewave at the rate of the received
AES/EBU signal
Xmit Clock Squarewave at 256x the programmed internal
sample rate
Rcvr Clock Squarewave at 256x the received sample rate
Jitter Generator Squarewave at Jitter Frequency
Digital Signal Generator Squarewave at digital generator frequency for
scope trigger
AES Interface Error
Logic low on error detection
Analyzer Signal Monitors
Input Monitor
Buffered version of the analog or digital input
signal. Amplitude is typically 0-2.83 Vpp.
Reading
Buffered version of the analog or digital analyzer
output signal after all filtering and gain stages.
Amplitude is typically 0-2.83 Vpp.
AUDIO MONITOR
Power Output Typically 1 Watt
D Specifications
Appendix D - Specifications
ATS-1 Dual Domain User's Manual D-13
