Response Selections
Weighted 4 Hz bandpass per IEC/DIN/NAB.
Unweighted 0.5 Hz–200 Hz.
Scrape
18
200 Hz–5 kHz.
Wideband
17
0.5 Hz–5 kHz.
Residual W+F
Weighted £0.001%.
Unweighted £0.002%.
Scrape or Wideband £0.005%.
Minimum Input 5 mV, 20 mV for specified residual.
Settling Time
IEC/DIN or NAB Typically 3 seconds–6 seconds.
JIS Typically 15 seconds–20 seconds.
Analog Analyzer Chapter 6: Specifications
Getting Started with Your 2700 Series Instrument 63
18
Operational only with high-band test signals (11.5 kHz–13.5 kHz). Upper –3 dB rolloff is typically 4.5 kHz using
12.5 kHz.
