Installation Manual 58 Document #: LTRT-10205
Mediant 800 MSBG
¾ To upgrade firmware using the Software Upgrade Wizard:
1. Stop all traffic on the device using the Graceful Lock feature (refer to the warning
bulletin above).
2. Open the 'Software Upgrade Wizard' (Maintenance tab > Software Update menu >
Software Upgrade Wizard); the 'Software Upgrade Wizard' page appears.
Figure 3-33: Start Software Upgrade Wizard Screen
3. Click the Start Software Upgrade button; the 'Load a CMP file' Wizard page appears.
Note: At this stage, you can quit the Software Update Wizard, by clicking Cancel
, without requiring a device reset. However, once you start uploading a
cmp file, the process must be completed with a device reset.
4. Click the Browse button, navigate to the cmp file, and then click Send File; the cmp
file is loaded to the device and you're notified as to a successful loading.
5. Click one of the following buttons:
•
Reset; the device resets with the newly loaded cmp, utilizing the existing
configuration and auxiliary files.
•
Next; the 'Load an ini File' wizard page opens.
Note that as you progress by clicking Next, the relevant file name corresponding to the
applicable Wizard page is highlighted in the file list on the left.
6. In the 'Load an ini File' page, you can now choose to either:
• Click Browse, navigate to the ini file, and then click Send File; the ini file is
loaded to the device and you're notified as to a successful loading.
• Use the ini file currently used by the device, by not selecting an ini file and by
ensuring that the 'Use existing configuration' check box is marked (default).
• Return the device's configuration settings to factory defaults, by not selecting an
ini file and by clearing the 'Use existing configuration' check box.
