USER’S MANUAL / bit Tune /
88
Placing the EMS probe in the vicinity of electrical parts or on the car’s wiring with the engine running, you can identify
acoustically, through the internal speaker, the higher sources of electromagnetic interference.
Locate the noisiest areas, avoid them when wiring audio cables. Prefer the less disturbed areas for the installation of
audio equipment (amplifiers, processors, passive crossovers, etc.).
12V
EMS
PC ANALYZER
LINE NOISE
POWER
SEGNAL INPUT
SELECT
RIGHT
VOLUME
MONITOR
47 OHM
SPK SYM
NO LOAD
LEFT
PRE IN BNC SPK INPROBE
MIN • • MAX
LOAD SIMULATOR
SPEAKER IN
RIGHT
VOLUME
MONITOR
47 OHM
SPK SYM
NO LOAD
LEFT
SPK IN
MIN • • MAX
LOAD SIMULATOR
SPEAKER IN
BATTERY
GROUND
8
8.4 ELECTROMAGNETIC NOISE ANALYZER
HIGH NOISE
LOW NOISE / NO NOISE
