USER’S MANUAL / bit Tune /
99
10. TECHNICAL SPECIFICATIONS
POWER SUPPLY
Voltage 11 ÷ 15 VDC
Idling current 0.8 A
Internal fuse (Cylindrical fuse) 2 A delayed
INPUT RCA STAGE
Input sensitivity max ± 100 V pp
Bandwidth 20 kHz
INPUT BNC STAGE
Input sensitivity max ± 100 V pp
Bandwidth 20 kHz
INPUT HI LEVEL STAGE
Input sensitivity max ± 1000 V pp
Bandwidth 20 kHz
INPUT OPTICAL IN STAGE
Optical S/PDIF Max 192 KHz/24bit, PCM
INPUT MICROPHONE STAGE
Input for HSM microphone 1
Input for LPM microphone 1
OUTPUT STAGE
2 x Analog Pre Out 4 V RMS
2 x Hi-Level Out 5.5 V RMS
1 x Optical digital Out S/PDIF Max 192 kHz/24bit, PCM
FUNCTION AVAILABLE WITH PC
Processor Auto Setup
Source Check
RTA
Polarity Check
Oscilloscope
Power Meter
Distortion Meter
Generator
Player
Battery Test
Optical Cable Test
FUNCTION AVAILABLE WITHOUT PC
Load Simulator Speaker In
Hi-Level AER Test
Source Line Analyzer
Electromagnetic Sniffing Test
PC connections USB 1.0 / 2.0
Software/PC requirements Microsoft Windows XP, Vista o Windows 7 (32 bit o 64 bit)
Graphic card min. resolution 1024 x 600
Temperature range Operating: 0 °C to 55 °C (32°F to 131°F)
SIZE W (Width) x H (Height) x D (Depth) mm/inch 232 x 165 x 51 / 9.13 x 6.49 x2
Weight kg/lb 1,24 / 2.73
