auer 6P10 PILOT - Spare Parts

- 6P10 PILOT MANUAL -
32
Rep. Réf. Désignation
1 B1239277 1’’1/2 valve
2 B1593083
2 pces 1’’1/2 --> 1’’1/2 plumbing
 tting
3 B1244897
UPMXL 25-125 PWM circulator
pump
4 B1239236 1’’1/2 check valve
5 B1134481 1’’1/2 plumbing  tting
6 B4994834
PWM hydraulic set (for HRC
70
25kW
and 32kW)
7 B1239216 1/2’’ automatic air bleed
non
visible
B1244569 6 bar pressure sensor
9 B1239239 6 bar pressure relief valve
non
visible
B1244901 6kW electrical back-up
11 B4994835 Electronic set
12 B1244902 Terminal block
13 B1244769 Electronic power board
14 B4594836 Electronic control board
15 B1238802 Aquastat
17 B1759512 Electrical back-up patch
18 B4480011 Holder
19 B4485674 Electronic base
20 B1238928 Desludging valve
21 B1239275 1’’1/2 M/M valve
Note : Availability of spare parts :
Spare parts which belong our products are available during
10 years, from the end of the mass production, except from an
event beyond our control.
8 - SPARE PARTS
