auer HRC70 17 - INSTALLATION AND PLACEMENT OF THE PILOT UNIT

- INSTALLER HIGHTEMPERATURE ENERGY EFFICIENT HEAT PUMP MANUAL -
12
3.1.2.2 - Fitting the Pilot to the wall
3.1.2.3 - Fitting and placement
The Pilot must be  xed vertically to a strong supporting wall
using three Ø8 lag screws.
Removing the
front panel
The Pilot must be  tted at least 300mm above any obstacles to
enable the hydrualic connection to be made with the bottom of
the appliance.
It should be  tted at least 100mm away from the ceiling to allow
easy access to the manual air valve.
It must be  tted at least 100mm away from walls on either side.
