auer HRC70 17 - PERFORMANCE DATA TABLES; HRC70 Heat Pump, 17 kW Performance; HRC70 Heat Pump, 20 kW Performance; HRC70 Heat Pump, 25 kW Performance

- INSTALLER HIGHTEMPERATURE ENERGY EFFICIENT HEAT PUMP MANUAL -
58
A7.1 - HRC
70
Heat Pump, 17kW
A7.2 - HRC
70
Heat Pump, 20kW
A7.3 - HRC
70
Heat Pump, 25kW
When using a pure product that needs
to be diluted with water, mix the water,
anti-freeze and inhibitor together outside before
putting it into the installation.
RENDERING THE WARRANTY NULL & VOID
Any deterioration in the condition of the
appliances which is due to unsuitable
quality of  lling water and / or corrosion in the
absence of treatment products as described
above and / or improper degassing of the
installation will result in the warranty being
rendered null and void.
A7 - Performance tables
Temperature Temperature
Air Water Max. min. Max. min.
15°C 35°C 23.2 13.1 4.8 2.4 4.8
15°C 22.2 12.5 5.8 3 3.8
15°C 55°C 21.6 11.9 6.9 3.5 3.1
15°C 70°C 19.5 10.7 8.3 4.3 2.3
7°C 35°C 19.6 10.4 4.8 2.8 3.7
7°C 45°C 19.3 10.4 5.7 3.0 3.4
7°C 55°C 18.8 9.9 6.6 3.4 2.9
7°C 70°C 17.6 9.3 8 3.5 2.7
0°C 35°C 16.5 8.9 4.6 2.4 3.2
0°C 45°C 16.3 8.5 5.4 2.8 2.7
0°C 55°C 15.9 8.1 6.3 3.2 2.4
0°C 70°C 14.7 7.5 7.6 3.8 2
-7°C 35°C 14.2 7.4 4.5 2.3 3
-7°C 45°C 14 7.1 5.2 2.7 2.5
-7°C 55°C 13.5 6.8 6 3 2.2
-7°C 70°C 12.7 6.4 7.3 3.7 1.7
-15°C 35°C 11.8 6 4.2 2.2 2.8
-15°C 45°C 11.4 5.8 4.9 2.5 2.3
-15°C 55°C 11.1 5.6 5.6 2.9 2
-15°C 70°C * 10.8 5.5 7 3.5 1.5
-20°C 35°C 10 5.1 4 2.1 2.5
-20°C 45°C 9.8 5 4.7 2.4 2.1
-20°C 55°C 9.7 4.9 5.4 2.8 1.8
-20°C 70°C * 9.5 4.8 6.7 3.4 1.4
* When outdoor air tem
p
eratures are below -10°C, o
p
eratin
g
at 70°C is intermitten
t
Modulating thermal
heating capacity (kW)
Electrical power
consumption (kW)
COP
Temperature Temperature
Air Water Max. min. Max. min.
15°C 35°C 28.3 13.1 5.8 2.3 4.9
15°C 45°C 27.1 12.5 7.1 2.9 3.8
15°C 55°C 26.4 11.9 8.3 3.4 3.2
15°C 70°C 23.8 10.7 10.1 4.2 2.4
7°C 35°C 24 10.3 5.7 2.5 4.1
7°C 45°C 23.6 10.1 6.9 2.9 3.6
7°C 55°C 23 9.8 8 3.3 3
7°C 70°C 21.5 9.3 9.8 3.9 2.4
0°C 35°C 20.1 8.9 5.6 2.3 3.3
0°C 45°C 19.9 8.5 6.6 2.7 2.9
0°C 55°C 19.5 8.1 7.6 3.1 2.5
0°C 70°C 18 7.5 9.2 3.8 2.1
-7°C 35°C 17.3 7.4 5.4 2.2 3
-7°C 45°C 17.1 7.1 6.3 2.6 2.7
-7°C 55°C 16.4 6.8 7.2 2.9 2.3
-7°C 70°C 15.5 6.4 8.8 3.6 1.8
-15°C 35°C 14.4 6 5.1 2.1 2.8
-15°C 45°C 13.9 5.8 5.9 2.4 2.4
-15°C 55°C 13.5 5.6 6.8 2.8 2
-15°C 70°C * 13.2 5.5 8.5 3.4 1.6
-20°C 35°C 12.2 5.1 4.8 2 2.5
-20°C 45°C 12 5 5.6 2.3 2.1
-20°C 55°C 11.8 4.9 6.6 2.7 1.8
-20°C 70°C * 11.7 4.8 8.1 3.3 1.4
* When outdoor air tem
p
eratures are below -10°C, o
p
eratin
g
at 70°C is intermitten
t
Modulating thermal
heating capacity (kW)
Electrical power
consumption (kW)
COP
• Regularly check the Ph levels and % of
glycol in the installation
• Never top up glycol in your installation
without measuring the Ph to check that the
drop in the glycol % is not due to deterioration
in the glycol.
• When the Ph is acidic (<7) replace all of the
glycol after having drained and rinsed the
installation beforehand.
Temperatur
e
Temperatur
e
Air Water Max. min. Max. min.
15°C 35°C 19.8 8.9 4 1.6 4.9
15°C 45°C 18.9 8.5 4.9 2 3.9
15°C 55°C 18.4 8 5.8 2.4 3.2
15°C 70°C 16.6 7.2 7 2.9 2.4
7°C 35°C 16.7 7.2 4 1.7 4.3
7°C 45°C 16.5 6.5 4.8 1.8 3.6
7°C 55°C 16 6.1 5.6 2.1 3
7°C 70°C 14.6 5.7 6.7 2.4 2.3
0°C 35°C 14.1 6 3.9 1.6 3.3
0°C 45°C 13.9 5.8 4.6 1.9 2.7
0°C 55°C 13.2 5.5 5.3 2.1 2.4
0°C 70°C 12.2 5 6.3 2.6 2.1
-7°C 35°C 12.1 5 3.8 1.5 3
-7°C 45°C 11.6 4.8 4.4 1.8 2.5
-7°C 55°C 11.1 4.6 5 2 2.2
-7°C 70°C 10.5 4.3 6.1 2.5 1.7
-15°C 35°C 9.7 4.1 3.5 1.4 2.7
-15°C 45°C 9.4 3.9 4.1 1.7 2.3
-15°C 55°C 9.2 3.8 4.7 1.9 1.9
-15°C 70°C * 8.9 3.7 5.8 2.4 1.5
-20°C 35°C 8.3 3.5 3.4 1.4 2.5
-20°C 45°C 8.1 3.4 3.9 1.6 2.1
-20°C 55°C 8 3.3 4.6 1.9 1.8
-20°C 70°C * 7.9 3.3 5.6 2.3 1.4
* When outdoor air tem
p
eratures are below -10°C, o
p
eratin
g
at 70°C is intermitten
t
Modulating thermal
heating capacity (kW)
Electrical power
consumption (kW)
COP
