Actuator controls AUMATIC AC 01.1 / ACExC 01.1
DeviceNet Operation instructions
10
Functions Standard: Seating programmable
Limit or torque seating for end position OPEN and end position CLOSED
Torque monitoring over the whole travel
Torque by-pass, adjustable to up to 5 seconds
(no torque monitoring during this time)
Phase failure monitoring with automatic phase correction
Programmable behaviour in case of loss of bus communication
Running indication via indication lights
Positioner
4)
:
Nominal position value via DeviceNet interface
Programmable behaviour on loss of signal
Automatic adaptation of the dead band (adaptive behaviour selectable)
Change over between OPEN – CLOSE duty and modulating duty
via DeviceNet
Options: Process controller, PID
4)
:
Nominal process value via DeviceNet interface
Actual process value via 0/4 – 20 mA additional input
Programmable behaviour on loss of signal
Limitation of the control range
Change over between OPEN – CLOSE duty and modulating duty
via DeviceNet
Monitoring functions Programmable monitoring of the max. number of cycles, generates warning signal
Reaction monitoring for operation command (programmable from 1 to 15 seconds),
generates fault signal – results in switching off
Operating time monitoring (programmable from 4 to 1,800 seconds), generates warning
signal
Electronic name plate Ordering data: Commission number AUMATIC, commission number actuator,
KKS number (definition system for power plants), valve number,
plant number
Product data: Product name, works number actuator, works number AUMATIC
Software version logic, hardware version logic, date of final test,
wiring diagram, terminal plan
Project data: Project name, 2 freely definable customer fields with a max. of 19 digits
each
Service data: Service telephone, internet address, service text 1, service text 2
Logging of operating data A resettable counter and a lifetime counter for:
Motor running time, number of starts, torque switch trippings in end position CLOSED, limit
switch trippings in end position CLOSED, torque switch trippings in end position OPEN,
limit switch trippings in end position OPEN, torque faults CLOSED, torque faults OPEN,
motor protection trippings
Motor protection evaluation Standard: Monitoring of the motor temperature in combination with thermoswitches
in the actuator motor
Options: Additional thermal overload relay in the controls
PTC tripping device in combination with PTC thermistors in the actuator
motor
Electrical connections Standard: AUMA plug/socket connector with screw type connection
Threads for cable glands:
M-threads: 5 x M 25 x 1.5
Pg-threads: 5 x Pg 21
NPT-threads: 1 x 1" NPT / 3 x ¾" NPT
Options: G-threads: 1 x G ¾" / 4 x G ½"
Special threads, other than standard mentioned above, possible
Gold-plated control plug (pins and sockets)
Parking frame for wall mounting of the disconnected plug
Protection cover for plug compartment (when plug is removed)
Overvoltage protection (option) Protection of the actuator and control electronics against overvoltages of up to 4 kV
(not available for component redundancy)
Wiring diagram (basic version) ACP 11F1-2P0—E000 KMS TP102/001
4) Requires position transmitter in the actuator
