Address 63 (default setting) should not be used since this is the default
address for all DeviceNet devices. Use address 64 to activate the MAC ID
setting via DeviceNet (in this case the DeviceNet address can be defined via
Explicit Messages of the process control system, e.g. with RSNetWorx by
Allen-Bradley). Furthermore, the OFFLINE CONNECTION SET is activated
(see page 56).
.
Pressing the push-button accepts the input.
.
To return to the previous indication without accepting the entered value
press the push-button .
After having changed the actuator address, the AUMATIC must be switched
off for a short time. As an alternative, you may also disconnect the 24 V DC
DeviceNet voltage supply for a short time.
7.11 Further parameters of the DeviceNet interface
The DeviceNet interface of the AUMATIC has further parameters which can
be set in the same way:
Configuration of the Poll I/O connections
You can use these parameters to configure the DeviceNet data interface
(see also page 49 ff).
Menu structure:
MAIN MENU (M)
SETTINGS (M1)
DEVICENET 1 (M1M)
SELECTED CONS.PATH (M1MX5)
SELECTED PROD.PATH (M1MX6)
Standard value:
SELECTED CONS.PATH: PROCESS OUTPUT
SELECTED PROD.PATH
: PROCESS INPUT
Behaviour on loss of communication:
The parameter
BUS-OFF INTERRUPT determines the reaction of the
AUMATIC DeviceNet interface in case of major communication faults. With
the setting
HOLD IN BUS-OFF, the DeviceNet interface is set to the status
UNRECOVERABLE FAULT (see diagnosis indications in the display). The
setting
FULLY RESET CAN causes an automatic restart of the AUMATIC
DeviceNet interface for most of the communication faults.
Menu structure:
MAIN MENU (M)
SETTINGS (M1)
DEVICENET 1 (M1M)
BUS-OFF INTERRUPT (M1MX7)
Standard value:
BUS-OFF INTERRUPT: HOLD IN BUS-OFF
Setting the DeviceNet Heartbeat Message
The
HEARTBEAT INTERVAL parameter determines the interval for sending
the Device Heartbeat Message. This message contains the current status of
the AUMATIC DeviceNet interface.
Standard value:
HEARTBEAT INTERVAL: 0S
(Device Heartbeat Message deactivated)
Actuator controls AUMATIC AC 01.1 / ACExC 01.1
Operation instructions DeviceNet
23
