20.4 Offline Connection Set of the AUMATIC
The Offline Connection Set can be used to reconnect a DeviceNet node
after a COMMUNICATION FAULT STATE (due to a duplicate MAC ID or a
bus-off status) to the DeviceNet network.
The user first has to secure access to the Offline Connection Set using the
Offline Ownership Messages. Afterwards, the faulty AUMATIC can be visu-
ally identified via the Point to Point Identify Request Message. The visual
identification is ensured by blinking of all LEDs of the local controls.
20.5 Reset of the AUMATIC to the factory settings
By means of the Reset service (Service Code 05hex) of the Identify Object
(Class ID 01hex), the AUMATIC can be reset to the default settings (out of
the box defaults) (Reset Type = 1).
56
Actuator controls AUMATIC AC 01.1 / ACExC 01.1
DeviceNet Operation instructions
Menu Abbreviation
inthe display
Note
DV DN1 MODULE STATUS
Module status of the DeviceNet interface 1
NOT POWERED
No DeviceNet voltage supply available
DEVICE OPERATIONAL
AUMATIC is in the normal operation status (optimum status)
DEVICE IN STANDBY
AUMATIC is in the standby status and requires a new DeviceNet interface con-
figuration due to missing, incomplete or incorrect settings.
MINOR FAULT
AUMATIC has detected a fault which can be eliminated
UNRECOVERABLE
FAULT
AUMATIC has detected a fault which cannot be eliminated and has to be res-
tarted (either disconnect AUMATIC or DeviceNet voltage supply; there may be
a Duplicate MAC ID, the master must possibly be restarted or reconfigured).
DEVICE SELF TE-
STING
AUMATIC is in the internal diagnosis status.
DW DN1 CURRENT VALUES
Current values of the baud rate and the MAC ID of DeviceNet interface 1
DX DN2 HRDWR. VER.
1)
Hardware version of the DeviceNet interface 2
DY DN2 SFTWR.VER.
1)
Software version of the DeviceNet interface 2
DZ DN2 BUS STATUS
1)
Status of the DeviceNet interface 2;
contents identical to that of DeviceNet interface 1
Da DN1 NET STATUS
1)
Network status of the DeviceNet interface 2;
contents identical to that of DeviceNet interface 1
Db DN2 MODULE STATUS
1)
Module status of the DeviceNet interface 2;
contents identical to that of DeviceNet interface 1
Dc DN2 CURRENT VALUE
1)
Current values of the baud rate and the MAC ID of DeviceNet interface 2
1) Option, only available for component redundancy
