9.1.1 Detailed description of the input data
The input data are described below in alphabetical order.
Actuator controls AUMATIC AC 01.1 / ACExC 01.1
Operation instructions DeviceNet
31
Designation Description (if there is no further explanation in the text, the description for bit value = 1 applies)
Actuator moving
Collective signal: contains the result of a disjunction (or operation):
Running LOCAL, Running REMOTE, Running with handwheel
CLOSED position, (torque
seating in end position
CLOSED)
Torque switch and limit switch in direction CLOSE operated.
CLOSED position, (limit
seating in end position
CLOSED)
Limit switch in direction CLOSE operated
Command o.k. There is no wrong command (“Wrong command” signal negated)
Config. fault
Value = 1: Indicates a faulty configuration, i.e. the current setting of the AUMATIC is not valid, the
precise cause can be viewed via a diagnosis indication (D4) on the display.
Value = 0: AUMATIC has been correctly configured
DN1 Analog In1 loss Signal loss of the analogue input 1 at the DeviceNet interface 1
DN1 Analog In2 loss Signal loss of the analogue input 2 at the DeviceNet interface 1
DN1 dig.in 1 A 24 V signal is present at the digital input 1.
DN1 dig.in 2 A 24 V signal is present at the digital input 2.
DN1 dig.in 3 A 24 V signal is present at the digital input 3.
DN1 dig.in 4 A 24 V signal is present at the digital input 4.
EMCY STOP active The EMERGENCY STOP button (option) has been operated (see page 45).
EMERGENCY MODE Emergency mode is active
External control
External operation (option). Is set as soon as the BUS/REMOTE input is supplied with 24 V DC
(optional 115 V AC). Thus, the AUMATIC only reacts to operation commands of the I/O interface
or the external inputs bus (OPEN – STOP – CLOSE or MODE and 0/4 – 20 mA) (see page 42
ff).
Fault ind.
Value = 1: Collective signal: Contains the result of a disjunction (OR-operation) of all bits of the
byte 10 (Fault signals)
Value = 0: No faults are active. All bits in byte 10 (Fault signals) are cleared.
Feedback E2 loss A loss of signal has occurred in the actual position.
I/O1 Analog In1 loss
Loss of signal of the analogue input 1 of the parallel interface (only for DeviceNet in combination
with parallel interface).
I/O1 Analog In2 loss
Loss of signal of the analogue input 2 of the parallel interface (only for DeviceNet in combination
with parallel interface).
In intermed. position
If set if the actuator does not execute an operation command and is neither in end position OPEN
nor in end position CLOSED
Intermed. pos. 1 Intermediate position 1 is signalled
Intermed. pos. 2 Intermediate position 2 is signalled
Intermed. pos. 3 Intermediate position 3 is signalled
Intermed. pos. 4 Intermediate position 4 is signalled
Intermed. pos. 5 Intermediate position 5 is signalled.
Intermed. pos. 6 Intermediate position 6 is signalled.
Intermed. pos. 7 Intermediate position 7 is signalled.
Intermed. pos. 8 Intermediate position 8 is signalled.
Internal fault
The internal diagnostics of the AUMATIC have detected a fault (the exact cause can be viewed
on diagnosis page D2 and DQ of the display).
Internal warning
The internal diagnostics of the AUMATIC have detected a warning (the exact cause can be deter-
mined via diagnosis page D3 of the display).
Local sw. position Selector switch in position LOCAL
Loss of phase
One phase missing; help: Connect phase. When externally supplied with 24 V DC, the complete
AC power supply might be missing, check and connect if necessary.
LSC (WSR) Limit switch CLOSE right operated.
LSO (WOEL) Limit switch OPEN left operated.
No external controls There is no external operation (“External controls” signal negated)
