Actuator controls AUMATIC AC 01.1 / ACExC 01.1
DeviceNet Operation instructions
32
Designation Description (if there is no further explanation in the text, the description for bit value = 1 applies)
No internal feedback
Indicates that the position transmitter has not been adjusted to the limit end positions yet. To ad-
just the actuator: Move the actuator manually to the end positions OPEN or CLOSED via the
push-buttons on the local controls.
No loss of phase There is no loss of phase (“Loss of phase” signal negated)
No reaction Is set if the reaction monitoring of the AUMATIC has detected a fault.
No thermal fault There is no thermal fault (“Thermal fault” signal negated)
Not ready ind.
Value = 1: Collective signal: Contains the result of a disjunction (OR-operation) of all bits of the
byte 9 (Not ready ind.).
Value = 0: No signal is active in byte 9 “Not ready ind.”.
OPEN position, (limit sea-
ting in end position OPEN)
Limit switch in direction OPEN operated.
OPEN position, (torque
seating in end position
OPEN)
Torque switch and limit switch in direction OPEN operated.
Operation pause
Passing of operation pauses (reversing prevention time, dead time, pause times in stepping
mode)
P.-Feedback E4 loss Loss of signal of the actual process value E4 (only if PID controller is available and active).
Remote sw. position Selector switch in position REMOTE
Running CLOSE
Value = 1: Operation command (CLOSE or SETPOINT) from DeviceNet or local controls in direc-
tion CLOSE is executed. For operation in stepping mode, this signal is also active during an
off-time, the dead time and the reversing prevention.
Value = 0: No operation is carried out via DeviceNet
Running LOCAL Indicates the movement of the output drive during electrical operation from LOCAL
Running OPEN
Value = 1: Operation command (OPEN or SETPOINT) from DeviceNet or local controls in directi-
on OPEN is executed. For operation in stepping mode, this signal is also active during an
off-time, the dead time and the reversing prevention.
Value = 0: No operation is carried out via DeviceNet.
Running REMOTE Indicates the movement of the output drive during electrical operation from REMOTE
Running with handwheel Movement at the output drive without electrical operation command
Selector not remote
The selector switch in not in position REMOTE (either LOCAL or OFF, signal “REMOTE sw. posi-
tion” negated)
Setpoint E1 loss A loss of signal has occurred in the nominal position.
Setpoint position
The setpoint is within max. error variable (outer dead band). Signal occurs only if DeviceNet mas-
ter has set the Remote SETPOINT bit.
Starts/run
Indicates an exceeding of the set limits of the starts/run monitoring, indication is deleted automati-
cally.
Stepping mode Indicates that the actuator has entered the set stepping range while in stepping mode
Thermal fault
A thermal fault (motor protection) has occurred. Help: Cool down, wait or perform cool-down after
a reset with push-button “Reset” of the local controls. Check fuse F4.
Torque E6 loss A fault has occurred in the torque measuring.
Torque fault (CLOSE)
Torque fault CLOSE occurred (only torque or torque before limit, according to type of seating);
help: Reset with counter command, or with push-button “Reset” of the local controls.
Torque fault (OPEN)
Torque fault OPEN occurred (only torque or torque before limit, according to type of seating);
help: Reset with counter command, or with push-button “Reset” of the local controls.
TSC (DSR) Torque switch CLOSE right operated (storing).
TSO (DOEL) Torque switch OPEN left operated (storing).
Warning ind.
Collective signal: Contains the result of a disjunction (OR-operation) of all bits of the bytes 11 and
12 “Warning signals”.
Warning oper. time
Indicates that the set operating time for an operation from one end position to the other has been
exceeded, the next new operation command deletes this indication.
Wrong command
Value = 1: Indicates the fact that several operation commands were received simultaneously via
DeviceNet (e.g. Remote OPEN and Remote CLOSE simultaneously or Remote CLOSE/Remote
OPEN and Remote SETPOINT (nominal) simultaneously) or that the max. value for a nominal
position has been exceeded (nominal position > 1,000).
Value = 0: Operation commands are o.k.
