5. Technical data
Actuator controls AUMATIC AC 01.1 / ACExC 01.1
Operation instructions DeviceNet
9
Features and functions
Supply voltage Standard voltages:
Special voltages:
External supply of the electronics
(option)
24 V DC + 20 % / – 15 %,
current consumption: basic version approx. 200 mA, with options up to 500 mA
Motor controls Standard: Reversing contactors
1)
(mechanically and electrically interlocked)
for motor power up to 1.5 kW
Options: Reversing contactors
1)
(mechanically and electrically interlocked)
for motor power up to 7.5 kW
Thyristor unit (recommended for modulating actuators)
for motor power up to 1.5 kW, 500 V AC with internal fuses
for motor power up to 5.5 kW, 500 V AC, external fuses required
Control and output signals via DeviceNet interface
DeviceNet interface with
additional inputs
(options)
DeviceNet interface with 4 free 24 V DC inputs and 2 free 0/4 – 20 mA inputs. Signal
transmission via fieldbus interface.
DeviceNet interface with 24 V DC control inputs OPEN – CLOSE – EMERGENCY.
Selection of control mode via 24 V DC input BUS/REMOTE.
DeviceNet interface with 24 V DC control inputs OPEN – CLOSE and 0/4 – 20 mA input for
nominal position value
2)
(positioner).
Selection of control mode via 24 V DC inputs BUS/REMOTE and MODE.
DeviceNet interface with 24 V DC (optional 115 V AC) control inputs OPEN – STOP –
CLOSE – EMERGENCY and 0/4 – 20 mA input for nominal position value
2)
(positioner).
Selection of control mode via 24 V DC (optional 115 V AC) inputs BUS/REMOTE
and MODE.
Output signals via 6 programmable signal relays, position feedback 0/4 – 20 mA.
Voltage output Standard: Auxiliary voltage 24 V DC, max. 100 mA for supply of the control inputs,
galvanically isolated from internal voltage supply
Option: Auxiliary voltage 115 V AC, max. 30 mA for supply of the control inputs,
3)
,
galvanically isolated from internal voltage supply
Component redundancy (option) AUMATIC is equipped with an additional redundant DeviceNet interface
Local controls Standard: Selector switch LOCAL – OFF – REMOTE (lockable in all three positions)
Push-buttons OPEN – STOP – CLOSE – RESET
5 indication lights:
End position CLOSED and running indication CLOSE (yellow), torque fault
CLOSE (red), motor protection tripped (red), torque fault OPEN (red),
end position and running indication OPEN (green)
LC display, illuminated
Programming interface
Options: Release of the local controls:
with or without selector switch LOCAL – OFF – REMOTE
Operation of the actuator with the push-buttons
OPEN – STOP – CLOSE – RESET of the local controls can be disabled or
released via DeviceNet.
Special colours for the 5 indication lights:
End position and running indication CLOSED (green), torque fault CLOSE
(blue), torque fault OPEN (yellow), motor protection tripped (white),
end position OPEN (red)
Protection cover, lockable
Protection cover with indicator glass, lockable
Table 3: DeviceNet interface for actuator controls AC 01.1
3-ph AC
voltages/ frequencies
1-ph AC
voltages/ frequencies
Volt 220 230 240 380 400 415 440 460 480 500 Volt 110,115,120 220,230,240
Hz 50 50 50 50 50 50 60 60 60 50 Hz 50/60 50/60
3-ph AC
voltages/ frequencies
1-ph AC
voltages/ frequencies
Volt
525 575 660 690 Volt 208
Hz
50 50 50 50 Hz 60
1) The lifetime guaranteed by the manufacturer amounts to 2 million cycles. In case a higher number of cycles is to be expected, the use of thyristor units with nearly
unlimited lifetime is recommended
2) Only partly possible in connection with process controller PID, please contact AUMA
3) Not possible in combination with PTC tripping device
