17. Redundant bus connection with component redundancy (option)
The AUMATIC can be equipped with a second (redundant) DeviceNet inter
-
face. In this version, communication to the actuator can be established
simultaneously through both DeviceNet interfaces. If one of the DeviceNet
components fails, e. g. through cable break, the operation commands are
executed which are sent via the other DeviceNet component.
If there is a communication to the master available via both DeviceNet inter-
faces, the operation commands of the interface which first established a
communication to the master will be executed.
For the bus connection refer to page 15 ff.
17.1 Settings for the redundant DeviceNet interface 2 (component redundancy)
The redundant DeviceNet component 2 is set in the same way as the setting
for the DeviceNet component 1 (see page 20 ff) and via the following
menus:
Menu structure
MAIN MENU (M)
SETTINGS (M1)
DEVICENET 2 (M1M)
BAUDRATE SW.VALUE (M1NX0)
MAC ID SW.VALUE (M1NX2)
SELECTED CONS.PATH (M1NX5)
SELECTED PROD.PATH (M1NX6)
BUS-OFF INTERRUPT (M1NX7)
HEARTBEAT INTERVAL (M1NX9)
After the address or baud rate setting has been changed, the
AUMATIC must be switched off for a short time to activate
the settings. As an alternative, you may also disconnect the
DeviceNet voltage supply for a short time.
47
Actuator controls AUMATIC AC 01.1 / ACExC 01.1
Operation instructions DeviceNet
