9. Poll I/O data interface of the AUMATIC
9.1 Description of the input data
The following Assembly Objects are available for reading input data from the
AUMATIC or writing output data to the AUMATIC.
Actuator controls AUMATIC AC 01.1 / ACExC 01.1
DeviceNet Operation instructions
26
Parameters AUMATIC Display indications Setting via configuration tool
Parameter designation Parameter value Value Address
SELECTED
CONSUMED PATH
SELECTED CONS. PATH STANDARD OUT
1
Class ID 101 (65 hex)
Instance ID 1 (1hex)
Attribute ID 1 (1hex)
STANDARD 1 AN. OUT
2
PROCESS OUTPUT
3
SELECTED
PRODUCED PATH
SELECTED PROD. PATH STANDARD INPUT
1
Class ID 101 (65 hex)
Instance ID 1 (1hex)
Attribute ID 17 (11hex)
EXTENDED INPUT
2
EXTENDED 1 AN.INPUT
3
EXTENDED 2 AN.INPUT
4
ENHANCED INPUT
5
PROCESS INPUT 1
6
PROCESS INPUT 2
7
PROCESS INPUT 3
8
Table 10: Addressing the parameters via configuration tool
SELECTED PRODUCED PATH = 1
Data length = 4 byte
Bit
1514131211109876543210
Word 1
(actuator signals)
No external controls
— — — — —
Anlog In1 DN1 loss
Feedback E2 loss
Local sw. position
Remote sw. position
No thermal fault
No loss of phase
LSO (WOEL)
LSC (WSR)
TSO (DOEL)
TSC (DSR)
Word 2 (E2 Feedback)
E2 Feedback (0 – 1 000 per mil)
Standard Input
SELECTED PRODUCED PATH = 2
Data length = 6 byte
Bit
1514131211109876543210
Word 1
(actuator signals)
No external controls
— — — — —
DN1 Anlog In1 loss
Feedback E2 loss
Local sw. position
Remote sw. position
No thermal fault
No loss of phase
LSO (WOEL)
LSC (WSR)
TSO (DOEL)
TSC (DSR)
Word 2 (E2 Feedback)
E2 Feedback (0 – 1 000 per mil)
Word 3
(extended)
Running with
handwhl
Thermal fault
TSC (DSR)
TSO (DOEL)
—
No reaction
Running CLOSE
Running OPEN
Command o.k.
EMERGENCY
MODE
Running CLOSE
Running OPEN
Local sw. position
Remote sw. position
LSC (WSR)
LSO (WOEL)
Extended Input
