Actuator controls AUMATIC AC 01.1 / ACExC 01.1
Operation instructions DeviceNet
27
SELECTED PRODUCED PATH = 3
Data length = 8 byte
Bit
1514131211109876543210
Word 1
(actuator signals)
No external controls
—
—
—
—
—
DN1 Anlog In1 loss
Feedback E2 loss
Local sw. position
Remote sw. position
No thermal fault
No loss of phase
LSO (WOEL)
LSC (WSR)
TSO (DOEL)
TSC (DSR)
Word 2 (E2 Feedback)
E2 Feedback (0 – 1 000 per mil)
Word 3
(extended)
Running with
handwhl
Thermal fault
TSC (DSR)
TSO (DOEL)
—
No reaction
Running CLOSE
Running OPEN
Command o.k.
EMERGENCY
MODE
Running CLOSE
Running OPEN
Local sw. position
Remote sw. position
LSC (WSR)
LSO (WOEL)
Word 4
(analogue input 1)
Analogue input 1 (0 – 1 000 per mil)
1)
1) In word 4 the value of the first additional free analogue current input of the DeviceNet interface is transmitted. The start and end values can be set at the
AUMATIC via the push-buttons and the display. For further detailed instructions on the indication, operation and setting of the AUMATIC refer to the operation
instructions of the actuator (multi-turn actuator SA(R) … / part-turn actuator SG … with AUMATIC AC ...).
If the measuring values are 0.3 mA below the initial value a loss of signal is indicated. (refer to warning signals 2, byte 16)
Extended One Analog Input
SELECTED PRODUCED PATH = 4
Data length = 10 byte
Bit
1514131211109876543210
Word 1
(actuator signals)
No external controls
—
—
—
—
—
DN1 Anlog In1 loss
Feedback E2 loss
Local sw. position
Remote sw. position
No thermal fault
No loss of phase
LSO (WOEL)
LSC (WSR)
TSO (DOEL)
TSC (DSR)
Word 2 (E2 Feedback)
E2 Feedback (0 – 1 000 per mil)
Word 3
(extended)
Running with
handwhl
Thermal fault
TSC (DSR)
TSO (DOEL)
--
No reaction
Running CLOSE
Running OPEN
Command o.k.
EMERGENCY
MODE
Running CLOSE
Running OPEN
Local sw. position
Remote sw. position
LSC (WSR)
LSO (WOEL)
Word 4
(analogue input 1)
Analogue input 1 (0 – 1 000 per mil)
1)
Word 5
(analogue input 2)
Analogue input 2 (0 – 1 000 per mil)
1)
1) In word 4 and 5, the values of the analogue current inputs of the DeviceNet interface were transmitted. The start and end values can be set at the AUMATIC via
the push-buttons and the display. For further detailed instructions on the indication, operation and setting of the AUMATIC refer to the operation instructions of
the actuator (multi-turn actuator SA(R) … / part-turn actuator SG … with AUMATIC AC ...).
If the measuring values are 0.3 mA below the initial value a loss of signal is indicated. (refer to warning signals 2, byte 16)
Extended Two Analog Input
