Autonics TK Series User Manual

6 Parameter Settings and Functions
100 © Copyright Reserved Autonics Co., Ltd.
6.7.2.2 Stop alarm output [PAR5 → StAL]
Enable or disable alarm output upon a stop.
Setting
Description
OFF
Alarm output ceases along with a stop under all conditions.
(However, reverting to RUN mode after a stop in alarm latch or
alarm latch and standby sequence restores the alarm output to
the previous state.)
CONT
Alarm output continues regardless of control operation.
Setting
group
Parameter Setting range
Factory
default
Unit
PAR1 R-S CONT / OFF CONT -
6.7.3 Multi SV
Multi SV function allows users to set multiple SVs and save each setting in SV0 to SV3. Users
can change SV-N or select desired SV using external digital input terminal (digital input, DI-1,
DI-2) function.
This feature supports up to four SVs which can be independently configurable.
6.7.3.1 Number of Multi SVs [PAR5 → MtSV]
This parameter sets the number of Multi SVs. Select the number of Multi SVs required by the
control subject.
Number of SVs SV Assignment
1 EA
SV-0
2 EA SV-0, SV-1
4 EA SV-0, SV-1, SV-2, SV-3,
Setting
group
Parameter Setting range
Factory
default
Unit
PAR5 MtSV 1 / 2 / 4 1
Number
of SVs
If the digital Input (DI-1, DI-2) feature has been set for multi SV [MtSV], the number of Multi SV
is not modified through pressing key or communication.(regardless of parameter mask)
6.7.3.2 Multi SV No. selection [PAR1 → SV-N]
Select the SV to control.
Setting
group
Parameter Setting range
Factory
default
Unit
PAR1 SV-N SV-0 / SV-1 / SV-2 / SV-3 SV-0 -
The range of figures assigned to each SV (SV No.) varies depending on the number of Multi SVs
[MtSV] setting.
