Autonics TK Series User Manual

1 Product Introduction
20 © Copyright Reserved Autonics Co., Ltd.
1.3 Ordering information
TK 4 S - 1 4 R R
①
②
③
④
⑤
⑥
⑦
Category
Description
① Item
TK Temperature/Process controller
② Digit
4 9999(4digit)
③ Size
N
DIN W48
×
H24mm
SP
DIN W48
×
H48mm (11 pin plug type
※
9
)
S DIN W48
×
H48mm (terminal block type)
M DIN W72
×
H72mm
W DIN W96
×
H48mm
H DIN W48
×
H96mm
L DIN W96
×
H96mm
④ Input/Output
Option
※
1
N
1
Standard: Alarm output 1+CT input
※
6,
Heating&Cooling: Alarm output 2
※
7
2 Standard: Alarm output 1+Alarm output 2
D Standard: Alarm output 1+Digital input(DI-1, DI-2)
R
Standard: Alarm output 1+Digital input, Heating&Cooling:
Trans. output
T
Standard: Alarm output 1+RS485com. output
Heating&Cooling: RS485com. output
S
P
1 Alarm output 1
S
M
W
H
L
1 Alarm output 1
2 Alarm output 1+Alarm output 2
R Alarm output 1+Trans. output
T Alarm output 1+RS485com. output
A Alarm output 1+Alarm output 2+Trans. output
B
Alarm output 1+Alarm output 2+
RS485 com. output
D
Alarm output 1+Alarm output 2+Digital input(DI-1, DI-2)
※
8
⑤ Power Supply
2
※
5
24VAC 50/60Hz, 24-48VDC
4 100 to 240VAC, 50/60Hz
⑥ OUT1 Control
Output
※
2
R Relay output
S
※
4
SSR drive output(standard ON/OFF, cycle, phase control)
C Current output or SSR drive output selectable
⑦ OUT2 Control
Output
※
3
Standard
N
None
※Select in case of standard control (heating or cooling)
Heating
&
Cooling
R Relay output
C Current output or SSR drive output selectable
