Autonics TK Series User Manual

6 Parameter Settings and Functions
© Copyright Reserved Autonics Co., Ltd. 101
6.7.3.3 Multi SV settings [PAR1 → SV-0/ SV-1/ SV-2/SV-3]
Designate the value of each SV for Multi SVs.
Setting
group
Parameter Setting range
Factory
default
Unit
PAR1
SV-0
Setting value low-limit [L-SV]
to Setting value high-limit [H-SV]
0
℃,℉,-
SV-1
SV-2
SV-3
6.7.4 Digital input
6.7.4.1 Digital input terminal settings [PAR5 → DI-1/DI-2]
By connecting an external input to a digital input terminal, you can perform preset digital input
terminal functions.
Setting Description
OFF
No function
STOP Run/Stop
AlRE
Alarm output deactivation
MAN
Auto/manual control selection
AT
Auto-tuning start
MtSV
Multi SV selection
In the case one of DI-1 or DI-2 being set for Multi SV[MtSV], SV-0 is selected as the SV if the
terminal's external contact signal is off and SV-1 is selected if the signal is on.
If both DI-1 and DI-2 are configured for Multi SV[MtSV], you can select the SV using
combinational logic of the terminals. If multi SV [MtSV] are changed from 4 to 2, DI-2 will be
turned OFF automatically, changed from 4 to 1, both DI-1 and DI-2 will be turned OFF or
changed from 2 to 1, concerned DI will be OFF.
DI-1
DI-2
Multi SV No.
OFF
OFF
SV-0
ON
OFF
SV-1
OFF
ON
SV-2
ON
ON
SV-3
Setting
group
Parameter Setting range
Factory
default
Unit
PAR5
DI-1
OFF / STOP / AlRE / MAN / MtSV OFF -
DI-2
When powered on, the digital input feature checks always the settings of terminal input.
Multi SV parameter will be activated only if Multi SV is more than 2.
The TK4SP Series has a limited number of terminal blocks and does not feature a digital input
terminal. Therefore, the digital input terminal functions are not available.
TheTK4S, M Series has a limited number of terminal blocks. Therefore, the digital input
terminal1 (DI-1) is available. (In case of TK4S-D4 □□, only DI-1, DI-2 are available)
