Autonics TK Series User Manual

6 Parameter Settings and Functions
© Copyright Reserved Autonics Co., Ltd. 73
 Make sure that SSRP function is not available for OUT2. In case of current type models,
SSR is fixed to standard output [STND] only.
 When selecting cycle output [CYCL] or phase output [PHAS], the power supply for the load
and temperature controllers must be the same.
 In case of selecting SSRP function whether cycle output [CYCL] or phase output [PHAS]
with PID control type, control cycle is not available to set.
6.2.5.3 Current output range settings [PAR3 → O!MA/O@MA]
If the control output is set to current output, you can select upper and low-limit range for the
current output as either 4-20mA or 0-20mA.
 O!MA: Sets OUT1's current output range.
 O@MA: Sets OUT2's current output range.
This parameter is only available on models supporting current output [OUT1, OUT2].
6.3 Temperature control
6.3.1 Temperature control mode [PAR3 → C-MD]
You can choose the type of temperature control method.
Setting
Description
Heating
Cooling
Standard
Control
PID
PID control
ONOF
ON/OFF control
Heating &
Cooling
Control
pP
PID control
PID control
pON
PID control
ON/OFF control
OnP
ON/OFF control
PID control
OnON
ON/OFF control
ON/OFF control
Setting
group
Parameter Setting range
Factory
default
Unit
PAR3 C-MD
Standard
Control
PID / ONOF PID
-
Heating &
Cooling
Control
pP / pON / OnP / OnON pP
