6.2.2 MV High/Low-limit value settings [PAR2 → H-MV / L-MV]
MV high/low-limit values [H-MV / L-MV] for control output can be configured to the actual MV,
provided the temperature controller's MV calculation exceeds the limits.
During heating & cooling control, cooling MV carries a "-" prefix. Therefore, the high-limit is
expressed as a + value on the heating side and the low-limit as a - value on the cooling side.
Parameter Description
L-MV
MV Low-limit value setting
H-MV MV High-limit value setting
Setting
group
Parameter Set range
Factory
default
Unit
PAR2
H-MV
Standard Control: MV Low-limit value [L-MV]
+ )1 to 10)0
10)0 %
Heating & Cooling Control: 00)0 to 10)0
(PID control)
)0 (OFF)/10)0 (ON) (ON/OFF control)
10)0 %
L-MV
Standard Control: 00)0 to MV high-limit value
[H-MV] – )1
)0 %
Heating & Cooling Control: `0)0 to 00)0
(PID control), `0)0 (ON)/ )0 (OFF) (ON/OFF
control)
`0)0 %
Same MV limits applied during auto-tuning.
MV limits are not applied to manual control, MV upon control stop, MV upon a sensor error, and
initial manual control MV.
MV high/low-limit configuration is not available for ON/OFF control in standard control mode
(heating or cooling control).
