Autonics TK Series User Manual

6 Parameter Settings and Functions
98 © Copyright Reserved Autonics Co., Ltd.
6.7 Additional features
6.7.1 Monitoring
Refer to ‘5.2.3 MV monitoring and manual control’.
6.7.1.1 Control output MV monitoring
Monitors and displays the current control output MV.
6.7.1.1.1. Heating MV monitoring
Displays the current heating MV during heating control or heating & cooling control.Users may
manually adjust the MV to control the temperature.
 Measurement range: H )0 to H100 (Unit: %)
Capable of displaying MV with a moving decimal point (H9(9 → H100).
6.7.1.1.2. Cooling MV monitoring
Displays the current cooling MV during cooling control or heating & cooling control.Users may
manually adjust the MV to control the temperature.
 Measurement Range: C )0 to C100 (Unit: %)
Capable of displaying MV with a moving decimal point (C9(9 → C100).
6.7.1.2 Heater current monitoring [PAR1 → CT-A]
A feature that monitors and displays the current of a heater (load) being controlled by control
output.
Setting
Group
Parameter Measurement range Unit
PAR1 CT-A )0 to 5)0 A
A current transformer (CT) is used to measure and display the heater's (load) current.
