Autonics TK Series User Manual

2 Specifications
26 © Copyright Reserved Autonics Co., Ltd.
Integral time (I) 0 to 9999sec.
Derivative time (D) 0 to 9999sec.
Control period (T)
Relay output, SSR drive output: 0.1 to 120.0 sec.
Current output+SSR drive output: 1.0 to 120.0 sec.
Manual reset value
0.0 to 100.0%
Sampling period 50 ms
Dielectric strength 2,000 VAC 50/60 Hz for 1 min. (between power source terminal and input terminal)
Vibration resistance
0.75mm amplitude at frequency of 5 to 55 Hz (for 1 min.) in each of X, Y, Z directions
for 2 hours
Relay
life
cycle
Mechanical
OUT1/OUT2: Min. 5,000,000 operations
AL1/2: Min. 20,000,000 operations (TK4H/W/L: Min. 5,000,000 operations)
Electrical
OUT1/OUT2: Min. 200,000 operations
AL1/2: Min. 100,000 operations(TK4H/W/L: Min. 200,000 operations)
Insulation resistance Min. 100MΩ (at 500VDC megger)
Noise resistance
Square shaped noise by noise simulator (pulse width 1 ㎲) ±2 kV R-phase, S-phase
Memory retention Approx. 10 years (non-volatile semiconductor memory type)
Environ
-ment
Ambient
temp.
-10 to 50℃, Storage: -20 to 60℃
Ambient
humi.
35 to 85% RH, Storage: 35 to 85% RH
Protection IP65 (front panel) ※TK4SP: IP50 (front panel)
Insulation type
Double insulation or reinforced insulation (mark: , dielectric strength between the
measuring input part and the power part: 2kV)
Approval
Weight
※
2
Approx.
140 g
(Approx.
70 g)
Approx.
130 g
(Approx.
85 g)
Approx.
150 g
(Approx.
105 g)
Approx.
210 g
(Approx.
140 g)
Approx. 211 g
(Approx. 141 g)
Approx.
249 g
(Approx.
198 g)
※1. At room Temperature range(23℃ ± 5℃)
 TC K, J, T, N, E type , below -100℃ / TC L, U, PLⅡ, RTD Cu50
Ω, DPt50Ω:
(PV ±0.3% or ±2℃, select the higher one) ± 1digit
 TC C, G, R, S type bellow 200℃: (PV ±0.3% or ±3℃, select the higher one)
± 1 digit
 TC B type, below 400℃: There is no accuracy standard.
Out of room temperature range
 RTD Cu50
Ω, DPt50Ω: (PV ±0.5% or ±3℃, select the higher one) ±1digit
 TC R, S, B, C, G type: (PV ±0.5% or ±5℃, select the higher one) ±1digit
 Others, Below -100℃, Within ±5℃
In case of TK4SP Series, ±1℃ will be added to the degree standard.
※2. The weight is with packaging and the weight in parentheses is only unit weight.
※Environment resistance is rated at no freezing or condensation.
