Power Consumption
asafeinstall_dgb, AutroSafe Interactive Fire Detection System, Release 4,
116-P-ASAFE-INSTALL/DGB, Doc-1004796-2, 2021-08-23, Autronica Fire and Security AS
Page 32
7. Power Consumption
7.1 Mains Power
7.1.1 STX Power
Refer to datasheet for Power Cabinet STX and the documentation for
each variant (2A, 5A and 10A) found on the Autronica Product Web
(see links in this handbook, chapter 6.6).
7.1.2 BPS-410
The current consumption at 115V AC is 4,5A.
The current consumption at 230V AC is 1,9A.
The inrush peak current consumption is 35A.
7.2 System Units
System Unit
Current Consumption
Fire Alarm Control Panel BS-420
Controller BC-420
156mA/27V DC (idle)
Max. 340mA/27V DC
Repeater Panel BU-BV-420
156mA/22,2V DC (idle)
Max. 220mA/27V DC (lamp test)
Operator Panel BS-430
175mA/27V DC (idle)
Max. 340mA/27V DC (lamp test)
Power Board BSF-400
85mA
System Unit Current Consumption
7.3 Loop Units
For information on the current consumption for various loop units, refer
to technical specifications provided in the relevant datasheets.
