11. Installing I/O Modules
11.1 Introduction
This chapter provides information on the mounting and removal of I/O
modules.
Note that the internal Power Module (BSS-310A) and the
Communication Module (BSL-310) are already mounted in a fixed
position when the product leaves the factory.
11.2 Front View of I/O Module
Screw
terminal 1
Front view when mounted on rail
Screw
terminal 10
