Service and Maintenance
asafeinstall_dgb, AutroSafe Interactive Fire Detection System, Release 4,
116-P-ASAFE-INSTALL/DGB, Doc-1004796-2, 2021-08-23, Autronica Fire and Security AS
Page 61
14.3 Annual Service and Maintenance
The whole system (control panel, detectors, control functions) should be
inspected annually. An annual service inspection comprises the
following:
Step Description
To test the panel indicator lights and internal buzzer, press and hold the Reset button for at
least 5 seconds. All indicators are lit and the buzzer is turned on. The test will automatically
stop. The lamp test can be performed in access level 1 (no use of key).
Test all operating keys by pressing each key (refer also to Operator’s Handbook):
All buttons will give a short "Beep" when pressed, except Mute button, Menu button and
Reset System button (plus the ones that are not supported, see below).
Note that the left/right arrow buttons and the two buttons in the lowermost right hand corner
(indicated with a white line) are not yet supported:
‘
Perform a visual and functional inspection of manual call-points and automatic detectors.
Check the log for contaminated detectors (Service/Log menu).
Disable any alarm transference to the Fire Alarm Routing Equipment -FARE output.
Activate the alarm system. Test all sounders by activating an alarm from a corresponding
manual call-point.
Test all control functions.
Activate alarms from at least one detector/manual call-point in each zone and a check that all
respective outputs are activated.
Test the action of any auxiliary operating functions (disabling, cancelling and resetting
buttons).
Check the alarm transference outputs by connecting from outgoing outputs (potential free
relay and 24V output) activated by alarm in a zone.
Mute Panel button
Silence Alarms button
Reset System button
Menu button
Close Window button
Alphanumeric keyboard
Manoeuvre buttons
