Appendix B Power
asafeinstall_dgb, AutroSafe Interactive Fire Detection System, Release 4,
116-P-ASAFE-INSTALL/DGB, Doc-1004796-2, 2021-08-23, Autronica Fire and Security AS
Page 85
16.16 Part of an AutroFieldBus Network
As a part of an AutroFieldBus network, the power module is configured
before start-up using dipswitches, some data, for example, “Low
voltage”-warning is given from an AutroSafe configuration via
AutroFieldBus.
Diagnostic outputs are given onboard with LEDs and alarm relay, and
on AutroSafe panels with audible alarms and display messages.
The LEDs and fault relay will not indicate any failure before the
AutroSafe has AutroFieldBus connection and the AutroSafe system has
been initialized.
16.17 Power Unit BPS-410 as Standalone
In the standalone system, user input is given during installation only,
using dipswitches onboard. Set dipswitch S6.3 OFF to set the power
supply in standalone mode.
Diagnostic outputs are given onboard with LEDs and fault relay.
