Autronica AutroSafe - Dipswitch Tables for S5 and S6 Settings

Appendix B – Power
asafeinstall_dgb, AutroSafe Interactive Fire Detection System, Release 4,
116-P-ASAFE-INSTALL/DGB, Doc-1004796-2, 2021-08-23, Autronica Fire and Security AS
Page 81
16.10 Dipswitch table – S5 and S6
Dipswitch table – S5
S5.1
S5.2
Function
OFF
OFF
AutroFieldBus earth fault OFF
ON
ON
AutroFieldBus earth fault ON
Dipswitch table – S6
Switch
Name
Comment
S6.1
Earth Fault
ON: Earth fault monitoring
activated
OFF: Earth fault monitoring
deactivated
S6.2
--
NA
S6.3
AutroFieldBus
ON: AutroFieldBus connected
OFF: AutroFieldBus not
connected
Note: If S6.3 is set to OFF, a
fault message will appear. The
unit will not be approved
according to EN-54-4 (psu).
S6.4
Not used
NA
S6.5
Battery
ON: Battery connected
Batteries must always be
connected.
S6.6
Power Unit Type
ON: BPS-405 (obsolete)
OFF: BPS-410
