BS100 DYFI Operators handbook
P-BS100/FE - Rev.F / Doc/ 980114 18 Autronica Fire and Security AS
6.3 Menu operation
Information given in this section follows the MENU STRUCTURE given in
section 6.1.
That particular parts of the menu structure is shown prior to each section in
order to ease the function overwiew.
When the control panel front door is opened, the following text will appear
in the display:
AUTRONICA FIRE ALARM SYSTEM BS-100
USER MENU
Then the text changes to:
SELECT MAIN MENU PRESS ↵
↵↵
↵
USERS INSTRUCTION PRESS ß
ßß
ß
If the operator selects to read the short form users instruction by pressing the
ß arrow key in the key-pad, the following text will appear in the display:
USER INSTRUCTION. PANEL IS OPERATED BY
USING MENU FUNCTIONS. TO CONT. PRESS ß
ßß
ß
VARIOUS MENU FUNCTIONS ARE SELECTED BY
USE OF ßÝ
ßÝßÝ
ßÝ AND ßÝ
ßÝßÝ
ßÝ LAST PICT. NEXT PICT. ßÝ
ßÝßÝ
ßÝ
CHOSEN FUNCTION IN MENU IS MARKED AND
IS EXECUTED BY PRESSING ↵
↵↵
↵ ß
ßß
ß
Ý
ÝÝ
Ý
IN ADDITION TO MENU FUNCTIONS THERE ARE
TWO FUNCTIONS WHICH CAN BE USED ß
ßß
ß
Ý
ÝÝ
Ý
“RET” WHEN THIS FUNCTION IS CHOSEN,
YOU TAKE ONE STEP BACK IN MENU ß
ßß
ß
Ý
ÝÝ
Ý
WHEN SELECTING “MM” THAT TAKES
YOU BACK TO MAIN MENU ß
ßß
ß
Ý
ÝÝ
Ý
Operation
Short form
operators
instruction.
This appears on
the display on
the front panel
