BS100 DYFI Operators handbook
P-BS100/FE - Rev.F / Doc/ 980114 41 Autronica Fire and Security AS
10.4.1 Change (site data)
The “CHANGE” function gives possibilities for changing the existing data.
Password level 1 only for changing display and printer texts. Password level
2 gives possibilities to change all custom data.
The function has limited capacity. Max. 30 addresses can be changed or
added.
When selecting "SYSTEM", "DATA" and "CHANGE" the following text
will appear in the display:
CHANGE SITE DATA
ADDRESS: 0000 RET MM
When the address in question is selected by means of the arrow key, press
the
↵
↵↵
↵ key.
10.4.1.1 Display text - Change (Password protected on level 1)
The customised designed text will appear in the display eg.:
SITE DATA ADDRESS 0001
0001 LABORATORY 1. FLOOR . ROOM 3. ß
ßß
ß
By means of the two arrow keys ⇐ Þ the cursor is moved to left or right.
The changes are carried out by moving the cursor to the letter or figure to be
changed and pressing the ß Ý arrow keys. Letters in alphabetic order,
figures and special signs scroll every time one of the two keys is pressed.
After changing the display text, move the cursor to the end of the line and
then the reference number for the printer text will appear in the display (
password level 1).
10.4.1.2 Printer text - Changes (Password protected on level 1)
On password level 2, the output control data will appear on the display when
moving the cursor to the end of the line.
SITE DATA ADDRESS 0001
PRINTER TEXT 0001 ß
ßß
ß
Ý
ÝÝ
Ý
Change the ref. number for the printer text and move the cursor to the end
of the line.
