BS100 DYFI Operators handbook
P-BS100/FE - Rev.F / Doc/ 980114 14 Autronica Fire and Security AS
5. Fault
5.1 Indications on the control panel in the event of
“FAULT”:
5.1.1 Indications at more (multiple) fault
If more (multiple) faults (here we show two) the following indications can
be shown in the display:
FA 01 ADERESS NO: 0123
LOOP/DET.FAULT: 1 SYSTEM FAULT: 1
Print out on optional printer:
This text means that there is one fault present on detector no. 0123, and that
there is one system fault present (sounder circuit). The nature of the fault
can be identified by using the menu.
Access to the menu is obtained by pressing the
-button on the five
elements key-pad.
1: The amber (yellow)
FAULT lamp lights with
pulsating light.
3: The internal buzzer is
activated.
Functions activated at “Fault”:
BMF - Common fault warning output.
****SYSTEM FAULT****
DATE: 25.11.91 T1.09.52
SF 1 SOUNDER CIRCUIT 4 OPEN
****DETEKTOR FAULT****
DATE: 25.11.91 T1.09.50
FA 1 ADDRESS NO: 0123
(EO) NO OR SHORT ANSWER-PULSE
2: The text display indicates the nature of
the fault. If the following letters are
indicated at the start of the upper line:
FA means loop / detector fault.
SF means system fault.
Fault
Indications
More faults
BS 100
DYFI
FIRE
MORE ALARMS
SOUNDER SILENCE
RESET
PREWARNING
FAULT
FUNCT. DISABL.
MAINS
A
utronica
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
DEVICE
(
S
)
STILL
IN ALARM COND.
