BS100 DYFI Operators handbook
P-BS100/FE - Rev.F / Doc/ 980114 31 Autronica Fire and Security AS
9. Test
Main menu
Test Front panel
BMA/BMF/BMFO
Fault
Sounders
Buzzer
When entering the "TEST"-function in the main menu, the following text
will appear in the display:
TEST
FRONT PANEL BMA/BMF/BMFO FAULT ß
ßß
ß
In the lower line the ß arrow indicates more text.
Move the cursor to the required function and press the ↵
↵↵
↵ key.
9.1 Front panel
If the "FRONT PANEL" function is selected, the display is tested by
showing all characters, and all lamps on the control panel front will light.
The function is stopped by pressing any of the arrow keys. A special test
sequence is also printed out on the optional printer, if this is installed.
Repeater units may also be tested in this function by opening door
(BU-100/101) or operating test button (BU-70).
9.2 BMA/BMF/BMFO
If the "BMA/BMF/BMFO" function is selected the following text will
appear in the display:
TEST OF TRANSMISS. LINE TO FIRE BRIGADE
WHEN COMPLETED PRESS ↵
↵↵
↵
This function will activate the corresponding outputs.
Inform the fire brigade if connected!
Test
Front panel
BMA/BMF/BMFO
!
