BS100 DYFI Operators handbook
P-BS100/FE - Rev.F / Doc/ 980114 29 Autronica Fire and Security AS
8. Show status
Main menu
Show status Alarm
Prewarning
Addr./loop-fault
System fault
Disablements
Alarmcounter
Stored events (last 150)
When "SHOW STATUS” is selected, the following text will appear in the
display:
SHOW STATUS SELECT WITH ⇐
⇐ ⇐
⇐ Þ
ÞÞ
Þ PRESS ↵
↵↵
↵
ALARM PREWARNING ADDR./LOOP-FAULT ß
ßß
ß
By pressing the ß key the rest of the text will appear in the lower line.
Alarm: The last 20 stored alarms
*)Prewarning: The last 20 active prewarnings.
*)Addr./loop-fault: The last 20 active faults from detectors/detector-
loops.
*)System fault: The last 20 active system faults.
Disablements: All stored disablements.
Alarmcounter: Number of stored alarms.
Stored-events: The last 150 stored events.
*) = These events are cleared when the "RESET"-button is pressed.
Move the cursor to the required function and press the ↵
↵↵
↵ key.
For the function "SHOW STATUS", option "ALARM", the text in the
display will be:
SHOW STATUS ALARM
ADDRESS 0296 DATE: 11.02.91 TI. 16.25
Use the ß Ý arrow keys to scroll through the stored alarms.
Use the ↵
↵↵
↵ arrow keys to return to "SHOW STATUS” menu.
"STORED EVENTS" is continually up-dated detailing the last 150 events in
the system. The last event will always be shown first.
Feed-paper
Service*
Out/in-control
Show status
Test
System
Main Menu
Show status
Stored events
