Appendix A - Country variations
A.1 Strapping
Within the menu / system text EPROM’s there is a country code that must
correspond to the code set with the function code straps (jumpers) W14,
W15, W16 and W17 located on the main board BSA-100. The function code
is used inside the system program to perform the required functions for that
particular country or market, (e.g. SOLAS and Offshore etc.).
Country Program code Function code
Menu program 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Norway P5-BS100-3N20 X X X
Sweden P5-BS100-3S20 X X X X
Denmark P5-BS100-3D20 X X X
England P5-BS100-3E20 X X X X
Finland P5-BS100-3F20 X X X
Holland P5-BS100-3H20 X X X
Italy P5-BS100-3I20 X X X X
Hungary P5-BS100-3U20 X X X X
Germany P5-BS100-3T20 X X X X
France P5-BS100-3A20 X X X X
Spain P5-BS100-3P20 X X X X
Poland P5-BS100-3L20 X X X
Strapping W14 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
field W15 1 1 1 1 0 0 0 0 1 1 1 1 0 0 0 0
ref. fig. 2.6 in W16 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0
Comm. handbook W17 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0
*) Function code 8 is SOLAS version
**) Function code 15 is OFFSHORE version
I = Installed strap
0 = Open strap
Function codes and belonging functions
Function code 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Function no.
Function number 0 7 2 1 1 5 0 0 16 7 0 1 0 0 0 16
See description 12 3 4 3 11 22 12 4 22
15 14 8 6 15 23 15 10 24
18 15 9 13 18 21 25
19 17 10 15 20 23
20 23 16
21
23
Menu Program P5
- BS100 - XNXX
Version no.
Language (N = Norwegian)
Program no.
Control panel type
Menu program
System Program P1
- BS100 - XXX
Version no.
System program
