BS100 DYFI Operators handbook
P-BS100/FE - Rev.F / Doc/ 980114 44 Autronica Fire and Security AS
Functions:
Function Description of function
no.
0 Standard function
1 LED no. 2, Lights up when alarm sounders are disabled
2 LED no. 2, Lights up when address control is activated
3 LED no. 3, Lights up when front door is open
4 LED no. 3, Lights up when BMA is disabled
5 Mains LED, Lights when the central panel has working
voltage 220V AC or 24V DC.
6 Mains LED, Lights when the central panel is in normal
condition
7 LED, “More alarms” is pulsating when more alarms is active,
and switched off at the first registrated alarm in the scrolling
function
8 Internal buzzer gives signal when detectors are disabled.
Silence by pressing silence sounder button.
9 Internal buzzer gives signal when BMA and AK are disabled.
Can not be silenced by silence sounder button.
10 Internal buzzer gives signal after pressing silence sounder
button in alarm condition.
11 Internal buzzer gives signal every 4th minute when the front
door is closed and the central panel is in abnormal condition
12 Disabling of internal buzzer when the front door is open
13 Disabling of BMA, BMFO and BMF when the front door is
open
14 Disabling of BMA, BMFO, BMF and output control when
the front door is open
15 Output no. 10 (SP) is active when the front door is open
16 System message is given 1 minute after interrupt of 220 VAC
17 System message is given 30 minutes after interrupt of 220 VAC
18 Silence sounders and reset buttons have to be operated for more
than 2 seconds
19 Only 4 digit of text on the first line, additional text on the
second line
20 BMF is active in normal condition and “OPEN” in fault
condition. Resets to active at silence sounders.
21 Disabling of detectors and alarm sounders can be password
protected on operator level in different countries
22 Alarm delay for marine installations (SOLAS).
See special description.
23 Automatic disabling of detectors in alarm condition after reset
has to be accepted within 10 seconds.
24 No automatic disabling of detector in alarm condition after reset
25 Reset time is programmed to be a minimum, also after alarm
